Selection of rules
With increasing number of transcription factors, co-occurrence analysis generally yields thousand of rules, which makes interpretation difficult. In this notebook, we will show how some different methods to select rules of interest from the original analysis. We will use the same data as within the ‘chipseq analysis’ notebook:
[1]:
import tfcomb.objects
C = tfcomb.objects.CombObj().from_pickle("../data/GM12878.pkl")
[2]:
C
[2]:
<CombObj: 112109 TFBS (151 unique names) | Market basket analysis: 10642 rules>
Select rules using co-occurrence measures
In this example, we will use the function .select_significant_rules() to select rules based on two measures. Default for this function are the “zscore” and “cosine” measures.
[3]:
selected = C.select_significant_rules()
INFO: x_threshold is None; trying to calculate optimal threshold
INFO: y_threshold is None; trying to calculate optimal threshold
INFO: Creating subset of TFBS and rules using thresholds
The function returns an instance of a CombObj containing only the selected rules and TFBS for the TFs within .rules:
[4]:
selected
[4]:
<CombObj: 83705 TFBS (86 unique names) | Market basket analysis: 282 rules>
[5]:
selected.rules
[5]:
TF1 | TF2 | TF1_TF2_count | TF1_count | TF2_count | cosine | zscore | |
---|---|---|---|---|---|---|---|
CTCF-RAD21 | CTCF | RAD21 | 1751 | 2432 | 2241 | 0.750038 | 18.643056 |
RAD21-SMC3 | RAD21 | SMC3 | 1376 | 2241 | 1638 | 0.718192 | 20.314026 |
CTCF-SMC3 | CTCF | SMC3 | 1361 | 2432 | 1638 | 0.681898 | 20.245177 |
IKZF1-IKZF2 | IKZF1 | IKZF2 | 1726 | 2922 | 2324 | 0.662343 | 11.215960 |
SMC3-ZNF143 | SMC3 | ZNF143 | 1060 | 1638 | 1652 | 0.644383 | 21.838431 |
... | ... | ... | ... | ... | ... | ... | ... |
GABPA-ZBED1 | GABPA | ZBED1 | 211 | 666 | 659 | 0.318495 | 14.915274 |
GABPA-MTA3 | GABPA | MTA3 | 216 | 666 | 692 | 0.318173 | 12.609150 |
CBFB-STAT5A | CBFB | STAT5A | 195 | 829 | 454 | 0.317855 | 15.633269 |
GABPA-NFATC1 | GABPA | NFATC1 | 214 | 666 | 681 | 0.317763 | 13.977084 |
ETS1-TAF1 | ETS1 | TAF1 | 166 | 424 | 644 | 0.317674 | 13.702745 |
282 rows × 7 columns
We will save this object for use in other notebooks:
[6]:
selected.to_pickle("../data/GM12878_selected.pkl")
The strictness of the selection can be controlled via x_threshold_percent and y_threshold_percent as seen here:
[7]:
C.select_significant_rules(x_threshold_percent=0.01, y_threshold_percent=0.01)
INFO: x_threshold is None; trying to calculate optimal threshold
INFO: y_threshold is None; trying to calculate optimal threshold
INFO: Creating subset of TFBS and rules using thresholds
[7]:
<CombObj: 30229 TFBS (29 unique names) | Market basket analysis: 22 rules>
Select top rules
We can also use the function .select_top_rules()
to select the first n rules from .rules:
[8]:
selected2 = C.select_top_rules(n=100)
[9]:
selected2.rules
[9]:
TF1 | TF2 | TF1_TF2_count | TF1_count | TF2_count | cosine | zscore | |
---|---|---|---|---|---|---|---|
CTCF-RAD21 | CTCF | RAD21 | 1751 | 2432 | 2241 | 0.750038 | 18.643056 |
RAD21-SMC3 | RAD21 | SMC3 | 1376 | 2241 | 1638 | 0.718192 | 20.314026 |
CTCF-SMC3 | CTCF | SMC3 | 1361 | 2432 | 1638 | 0.681898 | 20.245177 |
IKZF1-IKZF2 | IKZF1 | IKZF2 | 1726 | 2922 | 2324 | 0.662343 | 11.215960 |
SMC3-ZNF143 | SMC3 | ZNF143 | 1060 | 1638 | 1652 | 0.644383 | 21.838431 |
... | ... | ... | ... | ... | ... | ... | ... |
IKZF1-NFATC3 | IKZF1 | NFATC3 | 770 | 2922 | 1167 | 0.416980 | 6.271326 |
ATF7-IKZF2 | ATF7 | IKZF2 | 908 | 2061 | 2324 | 0.414886 | 2.376816 |
DPF2-IKZF1 | DPF2 | IKZF1 | 963 | 1844 | 2922 | 0.414864 | 0.597690 |
ATF2-EP300 | ATF2 | EP300 | 484 | 1484 | 922 | 0.413774 | 11.601051 |
CHD2-SP1 | CHD2 | SP1 | 219 | 611 | 460 | 0.413090 | 22.192709 |
100 rows × 7 columns
Select rules based on a list of TF names
If you are only interested in the rules concerning a list of TFs, it is possible to use .select_TF_rules
to subset the rules to a subset of TF names. Here, we create a subset of rules containing the TFs in TF_list:
[10]:
TF_list = ["ELK1", "CTCF", "ZNF143", "YY1"]
[11]:
selected3 = C.select_TF_rules(TF_list)
INFO: Selected 6 rules
INFO: Creating subset of object
[12]:
selected3
[12]:
<CombObj: 5686 TFBS (4 unique names) | Market basket analysis: 6 rules>
[13]:
selected3.rules
[13]:
TF1 | TF2 | TF1_TF2_count | TF1_count | TF2_count | cosine | zscore | |
---|---|---|---|---|---|---|---|
CTCF-ZNF143 | CTCF | ZNF143 | 1170 | 2432 | 1652 | 0.583713 | 15.459923 |
YY1-ZNF143 | YY1 | ZNF143 | 555 | 1365 | 1652 | 0.369591 | 6.797111 |
CTCF-YY1 | CTCF | YY1 | 481 | 2432 | 1365 | 0.263996 | -3.079479 |
ELK1-YY1 | ELK1 | YY1 | 88 | 237 | 1365 | 0.154718 | 4.946988 |
ELK1-ZNF143 | ELK1 | ZNF143 | 95 | 237 | 1652 | 0.151825 | 3.295755 |
CTCF-ELK1 | CTCF | ELK1 | 28 | 2432 | 237 | 0.036881 | -6.360275 |
It is also possible to specify that the rules should only be selected from matches to TF1 (by setting TF2=False):
[14]:
selected3 = C.select_TF_rules(TF_list, TF2=False)
INFO: Selected 257 rules
INFO: Creating subset of object
[15]:
selected3.rules
[15]:
TF1 | TF2 | TF1_TF2_count | TF1_count | TF2_count | cosine | zscore | |
---|---|---|---|---|---|---|---|
CTCF-RAD21 | CTCF | RAD21 | 1751 | 2432 | 2241 | 0.750038 | 18.643056 |
CTCF-SMC3 | CTCF | SMC3 | 1361 | 2432 | 1638 | 0.681898 | 20.245177 |
CTCF-ZNF143 | CTCF | ZNF143 | 1170 | 2432 | 1652 | 0.583713 | 15.459923 |
CTCF-TRIM22 | CTCF | TRIM22 | 900 | 2432 | 1786 | 0.431837 | 4.237106 |
YY1-ZNF143 | YY1 | ZNF143 | 555 | 1365 | 1652 | 0.369591 | 6.797111 |
... | ... | ... | ... | ... | ... | ... | ... |
CTCF-SUZ12 | CTCF | SUZ12 | 4 | 2432 | 172 | 0.006185 | -6.526432 |
CTCF-PAX8 | CTCF | PAX8 | 3 | 2432 | 165 | 0.004736 | -7.317208 |
CTCF-NFYA | CTCF | NFYA | 1 | 2432 | 21 | 0.004425 | -2.072913 |
CTCF-ZZZ3 | CTCF | ZZZ3 | 1 | 2432 | 32 | 0.003585 | -2.896546 |
CTCF-FOS | CTCF | FOS | 1 | 2432 | 45 | 0.003023 | -3.586322 |
257 rows × 7 columns
In case a TF is not found in rules, .select_TF_rules
will write a warning and raise an error:
[16]:
TF_list = ["NOTFOUND"]
selected_warning = C.select_TF_rules(TF_list)
WARNING: 1/1 names in 'TF_list' were not found within 'TF1' names: ['NOTFOUND']
WARNING: 1/1 names in 'TF_list' were not found within 'TF2' names: ['NOTFOUND']
InputError: No rules could be selected - please adjust TF_list and/or TF1/TF2 parameters.
